TitanEX(tm) 10 Position/11 Port With PCB
Description
This TitanEX model low pressure, 10-position, 11-port motorized selection valves that include a circuit board. This model accepts 1/6- tubing. The design of this valve provides a small footprint. A unique patented Tubing Connection System eliminates the need for threaded nuts and ferrules for tubing retention and liquid sealing.
Additional information
| For Tubing OD (in) | 1/8 |
|---|---|
| Material | RPC-7 |
| Ports | 11 |
| Positions | 10 |
| Pressure Rating Max (bar) | 9 |
| Pressure Rating Max (psi) | 125 |
| Valve Type | Selector w/PCB |
