DEGASi® PREP DEGASSER

The DEGASi® PREP vacuum degassing system for analytical instrumentation and HPLC removes dissolved gasses at flow rates up to approximately 15-20 ml/min per channel. Built for the rigours of modern preparative and semi-prep scale HPLC, its unique design assures reliable continuous operation and the highest level of continuous performance available. The low internal volume of each Systec AF™ channel offers quick equilibration and short startup times compared with PTFE degassers.
PRODUCT FEATURES
General Chamber Specifications

15 ml/min (Per Channel)
Degassing Channel Tubing:
Systec AF™ (0.075"e; ID)
Degassing Channel Pressure Rating:
70 PSI (testing pressure)
Wetted Materials:
Systec AF™, PPS, Glass-filled PTFE
Liquid Connection:
1/4’’-28 UNF threaded flat-bottom port
Size (L x H x B):
296 x 163 x 79 mm
POWER REQUIREMENT USING SUPPLIED AC ADAPTER
100 to 240 VAC (±10 %), 1 A,
50 to 60 Hz (±3 Hz)
Wall Sockets: 4 supplied with AC Adapter, interchangeable: North America/Japan, U.K., Continental Europe, Australia
Part no. | # channels | Channel Volume (ml) | Flow Rate Per Channel for 70% Gas Removed from 60% MeOH/40% water (ml/ min) | Pressure Drop (kPa/mL/min) |
---|---|---|---|---|
0041-2053 | 2 | 5,3 | 15 | 0,02 |
0041-4053 | 4 | 5,3 | 15 | 0,02 |
0001-2053 | Replaced by 0041-2053 | |||
0001-6482 | Replaced by 0001-0220 | |||
0001-6484 | Replaced by 0001-0220 |
