QuickStart(tm) Pressure Sensor Evaluation Kit 200 psi
Description
The new QuickStart(tm) pressure sensor evaluation kit comes with everything you need to test a sensor in a short amount of time. Included in the kit is a sensor, cables, USB adapter and memory stick (includes software). Available early 2017.
Additional information
| Color | No |
|---|---|
| Operating Voltage | 5.0V |
| Digital Communication Bus | 12C |
| Full Scale Pressure | 200 psi (14 bar) |
| Accuracy Below Full Scale | Less than 1% full scale |
| Full Scale Flow Rate | No |
| Flow Detection Response Time | No |
| Recommended Max Pressure | 400 psi |
| Burst Pressure | 800 psi (56 bar abs) |
| Wetted Materials | PEEK Housing, Viton O-ring, 315L SS |
| Ambient Storage Temperature | -30 – +100°C |
| Operating Temperature | +5 – +50°C |
| Pressure Detection Response Time | 67 ms |
