PEEK Manifold Assembly 9 Port, for 1/8″ OD

Description

Our PEEK Manifold Assembly can be applied for a multi-Ports mixing chamber, combining several fluid streams into one or one stream split to several outlets. It can also be used as a gas sparging splitting unions or sample injection onto multi-well plates or a multiple direction flow path union. Our manifold is manufactured from biocompatible PEEK giving it excellent chemical resistance. It has 9 Ports and is for 1/8″OD tubing. This assembly comes with Super Flangeless Fittings (9) P-331 and (9) P-359. Brochure

Additional information

For Tubing OD (in)

1/8

Material

PEEK

Pressure Rating Max (bar)

34

Pressure Rating Max (psi)

500

Swept Volume (µL)

160

Thread Port Configuration Flat-Bottom

1/4-28

Thru hole (in)

0.062

Thru hole (mm)

1.60
